Dual-Tenso – Multifunctional 2-Channel Converter for Strain Gauge Bridges

Dual-Tenso – Multifunctional 2-Channel Converter for Strain Gauge Bridges

SKU: MD61001
EAN: 5902186341180

The Modig MD61001 is a multifunctional measurement module designed to work with strain gauge load cells for weight measurement. It features two independent measurement channels that process signals from strain gauge bridges and route them to analog outputs—either voltage (0…10 V) or current (0/4…20 mA). All operating parameters as well as measured and calculated weight values can be read and modified via a USB-C interface emulating a serial port.

Key Features and Specifications
  • 2 measurement channels suited for connecting strain gauge load cells for weight measurement (strain gauge bridges)

  • 2 analog outputs—the analog output signal is proportional to the signals from the measurement bridges (proportional to the load on the strain gauge cell). Each output is independently configured and operates in one of 3 modes:
    – Voltage mode: 0…10 V
    – Current mode: 0…20 mA
    – Current mode: 4…20 mA

  • USB-C interface operating in CDC mode, emulating a serial port

  • Configuration of operating parameters and reading of measurement results via USB interface (including reading values converted into grams)

  • Control via simple text commands

  • Taring and calibration functions triggered via onboard pushbuttons or via the USB interface

  • Power supply: 24 V / 0.1 A

Package Contents
  • Multifunctional 2-channel converter for strain gauge bridges

  • USB cable with USB-A to USB-C connectors
