Modig ESP32-S3 DIN is a universal module designed for Internet of Things (IoT) applications. It is based on the modern ESP32-S3 controller, which features a dual-core XTensa LX7 processor clocked up to 240 MHz and provides Wi-Fi 2.4 GHz (802.11 b/g/n) as well as Bluetooth 5 (LE) wireless connectivity. Additionally, the MD43001 module includes two RS485 interfaces, two relay outputs, a USB interface, and a power supply system accepting voltages in the range of 7…32 VDC. The entire unit is housed in a compact enclosure suitable for DIN rail mounting.

The Modig Dual Tenso is a high-precision measurement module designed to work with two strain gauge load cells. While load cells are commonly used for applications such as weight measurement, they require a complex measurement circuit. The Modig Dual Tenso handles all necessary measurement and calibration functions, allowing the final result to be read via a USB (CDC) interface, as a 0…5V / 0…10V voltage signal, or as a 4…20 mA current loop signal.

The module features as many as 32 relays that can be controlled via three different interfaces: RS485, USB, and Qwire I2C. The RS485 interface enables connection to home automation installations; USB provides an easy way to interface with Single Board Computers (SBCs) like the Raspberry Pi; and Qwire I2C allows the module to be controlled even from small Arduino-family boards. The interfaces operate in parallel and are equipped with a series of protections that guarantee stable operation of the device, even in installations exposed to strong interference.

Modig ESP32-PoE is a universal module designed for Internet of Things (IoT) applications. It is based on the proven ESP32 controller, which features a dual-core XTensa LX6 processor clocked up to 240 MHz and provides Wi-Fi 2.4 GHz (802.11 b/g/n) as well as Bluetooth 4.2 (LE) wireless connectivity. Furthermore, the MD43002 module is equipped with a 10/100 Mbps Ethernet interface with a classic RJ45 connector and Power over Ethernet (PoE) support. The design is rounded out by RS485, USB (UART), and Qwire I2C interfaces, along with 4 universal outputs and a power supply system accepting voltages in the range of 7…32 VDC. This combination creates an exceptionally functional and easy-to-program, ready-to-use IoT module.
